2 Way Valve Manifolds
AVLOK 2 -Valve Manifolds offer safety and reliability in a general purpose design. The simple 2- Valve Configuration allows for easy block, bleed and calibration of a static pressure transmitter or gauge. Valves are available with either metal seats or replaceable soft seat inserts. Connections are 1/2 female NPT on all three ports.
SPECIFICATION
- Connection : 1/2″ Female NPT to 1/2″ Female NPT.
- One-piece, high strength body construction for safety no welding used.
- Stems feature an non-rotating top with an easily replaceable soft insert.
- Bonnet lock pin prevents accidental valve disassembly.
- 316 stainless steel construction for superior corrosion resistance.
- Bonnet-to-body seals are metal-to-metal-no O-Rings used.
- Mounting holes provided for self supporting applications.
- 100% pressure tested for shut-off and at all seals.
- Manifolds feature at 4:1 safety factor.
| No. | Description | SS316 VALVES |
BRASS VALVES | |
| 1. | BODY | 316SS | BRASS | |
| 2. | NUT | 316SS | BRASS | |
| 3. | FRONT FERRULE | 316SS | BRASS | |
| 4. | BACK FERRULE | 316SS | BRASS | |
| 5. | STEM | 316SS | 316SS | |
| 6. | PACKING RING | 316SS | BRASS | |
| 7. | PACKING | TFE | TFE | |
| 8. | PACKING GLAND | 316SS | BRASS | |
| 9. | PACKING NUT | 316SS | BRASS | |
| 10. | LOCK NUT | 316SS | BRASS | |
| 11. | HANDLE | STANDARD | P.C | P.C |
| ALTERNATIVE | 316SS(BAR) | BRASS(BAR) | ||
Product Enquiry
All Dimensions are for reference only, and are subject to change without prior notice. Sizes and types other than featured above are available on request.
